305×305 Urethane Screen Panels – Product Description Product OverviewThe 305×305 Urethane Screen Panel is a standard-size modular polyurethane screening media widely used in high-impact and abrasive screening environments. Manufactured from premium polyurethane with high tensile strength and exceptional wear resistance, these modular screen panels provide superior screening efficiency, long service life, and easy installation on…
Material: Polyurethane
Hardness: 80-95 Shore A
Customization: Available
Standard service life: 6~12 months
Delivery: 15-45 days depending on the quantity
A modular polyurethane screen panel is a good choice for many screening circuits, especially well suited for wet or dry applications. Also available in a variety of formulations including softer compounds that minimize or eliminate blinding.
Applications: dry as well as wet applications.
Size: 1ft*1ft, 1ft*2ft panels, also can make the size according to your special requirements, max length 3600mm panels.
Aperture options: Square, Slot, Round, Continuous slot, etc, size from 0.1mm to 170mm.
The screen panels are produced with open-cast polyurethane in steel molds to make sure the aperture sizes are accurate. Besides the screen panel holes adopts a conical design, which can prevent the plugging phenomenon during work and improve the screening efficiency.
1. Excellent abrasion resistance performance and long service life: 8`10 times longer than common wire mesh, 3 times longer than stainless wire mesh, and about 3.9 times longer than natural rubber. It has the best wear-resist performance in the mesh material.
2. Little work for maintenance, the polyurethane screen panel is heavy-duty structured and hard to be damaged under normal operation.
3. Low noise: our polyurethane and rubber screen media can reduce that noise level by as much as 9 decibels.
4. Variety of fastening options including Pin-Style, Pin and Sleeve, and Bolt Down, clips-on. Whether you need maximum holding power, ease of installation and removal, optimum versatility, or a combination of all of these, we have a fastening system to meet your needs.
Mesh: 0.15mm-10mm
Specification: 305*610/610*610/ Can be customized according to the customer’s use environment (single split block/double split block/water block)
Polyurethane Edged Screen Panel – Product Description IntroductionThe Polyurethane Edged Screen Panel is engineered for demanding screening environments where durability, precision, and stability are essential. The panel features a high-strength screening surface combined with molded polyurethane edges, offering superior performance in wet, dry, and highly abrasive material processing. Product Highlights Robust Screening SurfaceThe screen surface…
Polyurethane Edged Stainless Steel Screen Panel – Product Description Product OverviewThe Polyurethane Edged Stainless Steel Screen Panel is a high-performance screening media designed for mineral processing, aggregate production, coal preparation, and sand & gravel operations. It combines a stainless steel wire screening surface with durable polyurethane edging, providing exceptional wear resistance, high screening precision, and…
